This manual introduces the features and usage of the 73S1209F evaluation board.
This guide introduces the Teridian 73S1209F Evaluation Board, a 4‑layer development platform that demonstrates the capabilities of the 73S1209F Smart Card Controller. It details the kit contents, board features such as RS‑232, dual smart‑card interfaces, ICE/programmer connection, LCD module, keypad and LEDs, and recommended equipment for evaluation.
The manual covers board setup, including power options (7 V min / 12 V max, 400 mA) and connections to an emulator or PC, loading user code via the Signum ADM‑51 ICE or TSC Flash Programmer, using the pre‑loaded PCCID application, and hardware specifics like jumpers, switches, LCD and smart‑card interface circuitry. Ordering information and related documentation are also provided.
