This document describes the features and characteristics of ANSLEY® IDC SOCKETS 609 series female socket connectors, including physical properties, electrical properties, and environmental properties.
The catalog presents Tyco's preferred parts for the Ansley product line, including IDC socket connectors, low‑profile and right‑angle PCB headers, and vertical retainer/ejector latch headers. Each entry provides a Tyco order number, description, and key electrical and environmental specifications.
Later sections cover the TRIAD™ 20 system accessories such as sealing caps, back shells, and cable clamps, with cross‑reference tables for part numbers and mounting options. The document is intended for engineers and purchasing personnel needing detailed part data and ordering references.
| Current Rating | 1A |
|---|---|
| Insulation Resistance | >1 x 10^? 500 VDC |
| Dielectric Strength | >1000 VRMS at sea level |
| Temperature Rating | -55°C to +105°C |
| Insulation Material | Glass filled thermoplastic |
The connectors are rated for 1 A.
They operate from –55 °C to +105 °C.
The parts use glass filled thermoplastic for insulation.
The dielectric strength is greater than 1000 VRMS at sea level.
