RM2/3/7 is a power relay produced by Schneider Electric. It can be used in applications such as elevator control and power supply.
The Power Relay RM 2/3/7 series from Tyco (Schrack) are general‑purpose relays offered in 2‑pole and 3‑pole versions with contact ratings of 6 A, 10 A and 16 A. They support a switching capacity of up to 6000 VA and are suitable for applications such as elevator control and power supplies. The relays are RoHS compliant (Directive 2002/95/EC) and meet IEC 61810‑1 insulation standards.
The series includes a wide range of coil options (DC 6‑220 V, AC 6‑400 V) and mounting styles (plug‑in, PCB terminals, chassis‑ or DIN‑rail). Detailed part numbers, dimensions, and accessory options are listed, allowing designers to select the exact configuration needed for their system.
| Rated current | 6 A, 10 A, 16 A |
|---|---|
| Rated voltage (max switching) | 400/440 VAC |
| Switching capacity | 6000 VA |
| Mechanical endurance | 20 × 10⁸ cycles |
| Relay weight | 81 g |
| Packaging unit | 10–25 pcs |
| Ambient temperature range (DC coil) | -45 °C to 470 °C |
| Contact configuration | 2CO, 3CO |
The relay can handle a switching capacity of up to 6000 VA.
DC coil voltages from 6 V to 220 V and AC coil voltages from 6 V to 400 V are offered.
Yes, it complies with RoHS Directive 2002/95/EC.
