DS30487C PIC16F87/88 Data Sheet 18/20/28-Pin Enhanced Flash Microcontrollers
The PIC16F87/88 datasheet describes the 18/20/28‑pin enhanced flash microcontrollers with nanoWatt technology. It covers low‑power modes, memory organization (4 KB Flash, 368 B EEPROM, 256 B SRAM), oscillator options, peripheral modules such as CCP, SSP, AUSART, ADC, comparators, and special CPU features like extended watchdog and two‑speed start‑up.
The document also includes pin‑out diagrams for PDIP, SOIC, SSOP and QFN packages, packaging information, ordering details, and a worldwide sales and service contact list. Appendices provide revision history, device differences, and an index for quick reference.
| Operating Voltage Range | 2.0 V to 5.5 V |
|---|---|
| Sleep Mode Current | 0.1 pA at 2 V |
| Primary Run Mode Current | 76 µA at 1 MHz, 2 V |
| Number of I/O Pins | 16 |
The device draws 0.1 pA at 2 V in Sleep mode.
The PIC16F87/88 provides 16 user‑configurable I/O pins.
