This manual describes the functions and characteristics of the dsPIC30F5011 and dsPIC30F5013 devices, including electrical characteristics, pin configuration, register descriptions, instruction set, system clock and reset, memory organization, analog functions, system clock, timers, capture/comparators, DMA channels, SPI, I2C, UART, CAN, USB, real-time clock, power management, motor control, digital signal processing, software development tools, evaluation boards, and application notes.
This datasheet describes the dsPIC30F5011 and dsPIC30F5013 digital signal controllers, highlighting their 16‑bit MCU architecture with DSP extensions, high‑speed instruction set, and extensive peripheral set including timers, UARTs, CAN, SPI, I²C, and a 12‑bit ADC. It includes block diagrams, CPU architecture details, memory organization, and electrical characteristics.
The document also provides pin‑out diagrams for the 64‑pin and 80‑pin TQFP packages, ordering information, worldwide sales contacts, and legal notices. It serves as a reference for designers needing precise electrical and functional data for these devices.
| Flash program memory | 66 KB |
|---|---|
| Data RAM | 4 KB |
| Data EEPROM | 1 KB |
| Maximum performance | Up to 30 MIPS |
| External clock input | DC to 40 MHz |
| ADC resolution | 12‑bit |
| ADC conversion rate | 100 kS/s |
| ADC input channels | Up to 16 |
| I/O pin drive capability | 25 mA sink/source |
| CAN modules | Two CAN 2.0B compliant modules |
The devices can operate up to 30 MIPS.
Each device provides 66 KB of on‑chip Flash program memory.
The device integrates two CAN bus modules that comply with the CAN 2.0B standard.
