C.NF4T-M2 Ver1.4 motherboard uses ATX architecture, supports AMD Socket AM2 AMD Athlon 64 FX/Athlon 64 X2/ Athlon 64 /Sempron CPU, supports HyperTransport 1GHz, supports DDR2 533/ DDR2 667/DDR2 800 standard memory.
This manual describes the C.NF4T-M2 Ver1.4 motherboard built on an ATX chassis with an NVIDIA nForce4 chipset. It supports AMD Socket AM2 CPUs (Athlon 64 FX, Athlon 64 X2, Athlon 64, Sempron), dual‑channel DDR2 533/667/800 memory up to 2 GB, three PCI slots, one PCI‑Express x16 slot, two PCI‑Express x1 slots, four SATA ports with RAID 0/1/0+1/JBOD, two IDE ports, eight USB connectors, a 10/100 Mbps Realtek network controller and a six‑channel AC’97 audio codec.
The guide walks through hardware installation steps, jumper settings for CMOS clear and USB power selection, BIOS features (Award BIOS), and includes appendices with DOS‑mode BIOS flashing instructions and a glossary of motherboard abbreviations. This manual is written in Chinese.
| Supported CPUs | AMD Socket AM2 (Athlon 64 FX, Athlon 64 X2, Athlon 64, Sempron) |
|---|---|
| Chipset | NVIDIA nForce4 |
| Network Interface | Realtek RTL 8201CL 10/100 Mbps Ethernet |
| Audio Codec | 6‑channel AC’97, 16‑bit stereo decoding |
The board supports AMD Socket AM2 processors, including Athlon 64 FX, Athlon 64 X2, Athlon 64 and Sempron CPUs.
Short pins JCS2 2‑3 for about 3 seconds with the system powered off, then restore the jumper to pins 1‑2.
