A6GMV series motherboard user manual, introduces the characteristics and features of the motherboard, usage, installation, and usage precautions.
This manual covers the A6GMV series motherboard, detailing product specifications, layout diagrams, back‑panel connectors, and supported components. It includes safety notices, environmental compliance, and warranty statements.
The guide walks users through hardware installation (CPU, memory, expansion cards), BIOS settings, RAID configuration, and operating‑system installation, plus troubleshooting tips and contact information for technical support. This manual is written in Chinese.
| CPU socket | AMD AM3 |
|---|---|
| Maximum CPU power | 95 W |
| Chipset northbridge | AMD 690G |
| Chipset southbridge | AMD SB600 |
| Memory slots | 2 × 240‑pin DDR3 DIMM |
| Maximum memory | 8 GB |
| Expansion slots | 1 × PCI‑Express x16, 1 × PCI‑Express x1, 2 × PCI |
| Integrated graphics | ATI Radeon X1250 (DirectX 9.0) |
| SATA ports | 4 × SATA II (3 Gb/s) |
| RAID support | RAID 0, RAID 1, RAID 10 |
| Network controller | Realtek RTL8111D Gigabit |
| Audio codec | VIA VT1708s |
| USB ports | 8 × USB 2.0 |
| Form factor | Micro‑ATX (24.4 cm × 21.3 cm) |
The board supports up to 8 GB of DDR3 memory across its two 240‑pin DIMM slots.
