This manual introduces the features, functions and usage methods of the 649FX/6497AA series motherboard.
This manual provides detailed information about the Foxconn 649FX/6497AA series motherboard, including its main performance specifications, layout diagrams, rear panel description, and step‑by‑step hardware installation instructions. It also lists supported CPUs, memory types, interfaces, slots, jumpers, and BIOS protection features.
The document is organized into sections such as Product Introduction, Main Features, Motherboard Layout, Rear Panel, Installation Guide, CPU, Memory, Power Supply, Interfaces, Slots, Jumpers, and BIOS Protection. Each section includes diagrams, warnings, and practical tips for safe assembly and configuration. This manual is written in Chinese.
| Form factor | ATX, 294 mm × 208 mm |
|---|---|
| Supported CPUs | LGA775 Intel Pentium D, Pentium 4 Extreme Edition, Pentium 4, Celeron D |
| Chipset | SiS649FX/SiS649 northbridge + SiS965/SiS965L southbridge |
| USB ports | 8 × USB 2.0 (480 Mbps) |
| SATA support | Optional, up to 4 SATA devices (SiS965) or 2 (SiS965L) |
| LAN | Optional 10/100/1000 Mbps Ethernet |
It supports LGA775 Intel Pentium D, Pentium 4 Extreme Edition, Pentium 4 and Celeron D processors.
The board provides eight USB 2.0 ports.
It is an ATX board measuring 294 mm by 208 mm.
