The document is a technical manual about TLE 6225 G, which introduces the features of the product, including short circuit protection, overtemperature protection, overvoltage protection, open load detection, direct parallel control of inputs, high or low active inputs programmable, general fault flag, very low standby quiescent current, compatible with 3V microcontrollers, electrostatic discharge (ESD) protection, etc.
The TLE6225G is a four‑channel low‑side switch built with Infineon's Smart Power Technology. Each channel features short‑circuit, over‑temperature, over‑voltage and open‑load protection, and can be individually controlled via dedicated input pins and a common enable line. The device is designed for 12 V automotive and industrial systems, driving lines, lamps, relays and other loads.
The datasheet provides detailed pin‑out information, maximum ratings, electrical characteristics such as supply voltage (4.5‑32 V), on‑resistance (1.7 mΩ), output current (350 mA per channel) and thermal limits. It also includes diagnostic tables, typical characteristic curves, timing diagrams and package dimensions with ordering code P‑DSO‑20‑6.
| On‑Resistance (Ron) | 1.7 mΩ |
|---|---|
| Fault Current Limit | 500 mA |
| Operating Temperature Range | -40 °C to +150 °C |
| ESD Protection (Human Body Model) | 2000 V |
It provides four independent low‑side switch channels.
Yes, it includes ESD protection rated at 2000 V (Human Body Model).
