The TLE 6228 GP is a 4-channel low-side switch with 4 separate inputs and 4 open drain DMOS output stages. The TLE 6228 GP is fully protected by embedded protection functions and designed for automotive and industrial applications. Each channel has its own status signal for diagnostic feedback. Therefore, the TLE 6228 GP is particularly suitable for ABS or Powertrain Systems.
The TLE6228 GP is a smart quad‑channel low‑side switch designed for automotive and industrial control applications. It offers short‑circuit, overtemperature, overvoltage, and ESD protection, with separate diagnostic pins for each channel and low standby current.
The datasheet details electrical characteristics such as supply voltage range, on‑resistance, output current per channel, and protection thresholds, as well as pin configurations, package dimensions, and ordering information.
| Supply voltage (Vs) range | -0.3 V to +40 V |
|---|---|
| Continuous drain‑source voltage (Vos) | 45 V |
| Supply current (outputs ON) | 8 mA |
| Supply current (outputs OFF) | 4 mA |
| Standby current | 10 µA |
| Electrostatic discharge (ESD) rating | 2000 V (human body model) |
| Overtemperature shutdown threshold | 170 °C to 200 °C |
It is a quad‑channel low‑side switch, providing four independent channels.
The device operates with a supply voltage (Vs) from –0.3 V up to +40 V.
It includes short‑circuit, overtemperature, overvoltage, and electrostatic discharge protection.
The standby current is specified as 10 µA.
