This is the user manual for AMD Socket AM2/AM2+(940-pin) processor. It mainly introduces the motherboard accessories, installation, common jumper settings, system memory, common interface introduction, common BIOS settings, drivers and applications, common problem solving, and BIOS refresh.
This manual covers everything needed to install and configure an AMD Socket AM2/AM2+ (940‑pin) processor. It includes a list of packaging contents, detailed CPU installation procedures, jumper settings, memory configuration, and descriptions of common motherboard interfaces.
Additional sections explain BIOS configuration options, driver and application installation, a FAQ for common issues, and step‑by‑step instructions for updating the BIOS using the AWDFLASH utility. This manual is written in Chinese.
| CPU socket type | AM2/AM2+ (940‑pin) |
|---|
Turn off the computer, move the jumper from the 1‑2 position to 2‑3 for more than 4 seconds, then move it back to 1‑2 and restart.
Download the appropriate AWDFLASH.EXE tool and BIOS .bin file, copy them to a bootable DOS medium, run AWDFLASH, enter the BIOS file name, and follow the prompts.
