AMD Socket A Motherboard nForce2 Ultra 400 User Manual

This is a user manual for AMD Socket A processor, NVIDIA nForce2 Ultra 400 chipset motherboard. It introduces the package contents, specifications, installation, BIOS setup, S-ATA RAID configuration and driver installation in detail

Brand: AMD
Category: Motherboard
Document type: User Manual
Language: Chinese
Pages: 58
File format: PDF
File size: 13.2 MB
Published: 05 April, 2012
Updated: 30 September, 2023
Model: NFORCE2
MD5 checksum: 8BFEFFFE0260F64C4DBED0439C1695BF
PDF: AMD Socket A Motherboard nForce2 Ultra 400 User Manual PDF

About this manual

This manual provides detailed information for the AMD Socket A motherboard equipped with the NVIDIA nForce2 Ultra 400 chipset. It includes packaging contents, hardware specifications, installation procedures, BIOS configuration, and RAID options.

The document is organized into chapters covering specifications, CPU installation, peripheral connections, BIOS settings, and optional features such as SATA RAID. It also contains appendices with BIOS update instructions and safety warnings. This manual is written in Chinese.

What's inside

Packaging Contents
Specifications
CPU Installation
Peripheral Connections
BIOS Settings
RAID Configuration
SATA RAID
Appendix: BIOS Update
Safety and Warranty

Specifications

CPU Socket	462‑pin Socket A
Supported CPUs	AMD Athlon XP (1500‑3000 MHz) and AMD Barton (2500‑3200 MHz)
Maximum Memory Capacity	3 GB
Memory Channels	128‑bit dual‑channel
USB Ports	USB 2.0 x8
LAN Controller	Realtek RTL8201CL PHY (10/100 Mbps)
FireWire Controller	VIA VT6307 (1394) integrated
