EL7104 is a high-speed, single-channel, power MOSFET driver with matched rise and fall delay times, which improves the operation of TC-4420/29 clock drivers.
The EL7104 is a matched driver IC designed to improve the operation of industry‑standard clock drivers and power MOSFETs. It delivers peak currents of up to 1 A into capacitive loads and features matched rise/fall times, low output impedance, and reduced clock skew.
The device is offered in 8‑pin SOIC and PDIP packages, operates from –40 °C to +85 °C, and includes detailed absolute‑maximum ratings, electrical specifications, switching characteristics, and typical performance curves. Ordering information and package dimensions are also provided.
| Operating Temperature Range | -40 °C to +85 °C |
|---|---|
| Input Logic "1" Voltage (VIL) | 2.4 V |
The device operates from –40 °C to +85 °C.
