The AD8386 is a 10-bit, 12-channel output decimating LCD driver with features such as high voltage drive, output short-circuit protection, high update rates, and low static power dissipation.
The AD8386 is a 10‑bit, 12‑channel decimating LCD driver designed for high‑voltage video output. It features fast 100 Ms/s data update, 35 ns settling time to 0.25 % with 150 pF load, and built‑in overload and thermal protection. The device is offered in a 64‑lead LFCSP_VQ package and operates from 0 °C to 85 °C.
The datasheet provides detailed specifications, pin configurations, absolute maximum ratings, and recommended PCB layout for optimal thermal performance. It also includes serial interface details, timing characteristics, and ordering information.
| Static power dissipation | 1.4 W |
|---|---|
| Maximum power dissipation (typical) | 3.7 W |
| Output current per channel | 100 mA |
| Supply voltage (AVCC) | 9 V to 18 V |
| Supply voltage (DVCC) | 3.3 V to 45 V |
| Operating temperature range | 0 °C to 85 °C |
| Maximum data update rate | 100 Ms/s |
The AD8386 limits each output to an average of 100 mA.
The device dissipates 1.4 W of static power.
The device can update input data at up to 100 Ms/s.
