ADMTV300 is a single chip synthesized tuner for T-DMB, dual-band DAB and FM receiver, which adopts a low-IF single-conversion architecture that eliminates all SAW filters.
The ADMTV300 is a highly integrated CMOS low‑IF single‑conversion tuner IC designed for mobile applications such as terrestrial DMB, dual‑band DAB and FM. It integrates LNAs, RF PGA, mixer, adjustable band‑pass filter, IF programmable gain amplifier, VCO and fractional‑N PLL in a 5 mm × 5 mm 32‑LFCSP package.
Key features include ultra‑low power consumption (77 mW in Band‑III, 84 mW in L‑Band), a single 1.2 V supply, PC serial bus interface, and minimal external components, making it suitable for portable TV, PDA, car A/V and FM radio applications.
| Input sensitivity | -102 dBm |
|---|---|
| Power consumption (L‑Band) | 84 mW |
| Supply voltage | 1.2 V |
| FM frequency range | 88 – 108 MHz |
| L‑Band frequency range | 1450 – 1492 MHz |
| IF output | 540 kHz (FM) |
| Package | 32‑LFCSP (5 mm × 5 mm) |
The ADMTV300 has an input sensitivity of -102 dBm.
The ADMTV300 operates from a single 1.2 V supply.
It is offered in a 32‑LFCSP (QFN) package measuring 5 mm × 5 mm.
