AD1896 is a 24-bit high performance single-chip second-generation asynchronous sample rate converter
The AD1896 is a 24‑bit, high‑performance, single‑chip asynchronous sample‑rate converter supporting up to 192 kHz stereo operation. It offers features such as automatic sample‑frequency sensing, jitter attenuation, flexible 3‑wire serial interfaces, bypass mode, and matched‑phase operation.
The document provides detailed specifications including supply voltages, digital performance, timing diagrams, pin functions, power consumption, temperature ranges, absolute maximum ratings, ordering options, and typical performance graphs.
| Maximum Sample Rate | 192 kHz |
|---|---|
| Dynamic Range (A‑Weighted) | 142 dB |
| THD + N (worst case) | -133 dB |
| Supply Voltage (VDD_CORE) | 3.3 V |
| Supply Voltage (VDD_IO) | 5.0 V or 3.3 V |
| Operating Temperature Range | -40 °C to +105 °C |
| Package | 28‑Lead SSOP |
The device supports up‑sampling ratios of 1:8 and down‑sampling ratios ranging from 7.75:1 to 1:8.
The AD1896 requires a core supply of 3.3 V and an I/O supply of either 5.0 V or 3.3 V.
The AD1896 is available in a 28‑lead SSOP plastic package.
The device achieves a 142 dB A‑Weighted dynamic range at a 44.1 kHz to 48 kHz sample‑rate conversion.
