The document describes the features and characteristics of the AD8380 DecDriver™ decimating LCD panel driver. It has high-voltage drive capability, fast update rates, low power dissipation, flexible logic addressing, and sequential channel loading.
The AD8380 is a 6‑channel high‑voltage drive, decimating LCD panel driver offering fast update rates (75 Ms/s) and low power dissipation (0.55 W). It provides flexible logic, addressable or sequential channel loading, and can drive capacitive loads up to 150 pF with a 26 ns settling time.
The document includes full electrical specifications, pin‑out descriptions, functional block diagrams, absolute‑maximum ratings, and typical performance curves. It also outlines ordering information, ESD precautions, and recommended external components for reliable operation.
| AVCC Operating Range | 9 V – 24 V |
|---|---|
| Operating Temperature Range | 0 °C – 85 °C |
| Output Current | 30 mA |
| Slew Rate | 270 V/µs |
| Static Power Dissipation | 0.55 W |
The AD8380 can source up to 30 mA per output channel.
The device updates input data at 75 Ms/s.
When the STBY pin is high, all digital and analog circuits are debiased and power dissipation drops to a minimum.
The AD8380 is offered in a 44‑lead MQFP package measuring 10 × 10 × 2.0 mm.
