ADG411/ADG412/ADG413 are precision quad SPST switches with a maximum supply voltage of 44V and a ±15V analog signal range. They have low on resistance (<35Ω), ultralow power dissipation (35µW), and fast switching times (tON <175ns, tOFF <145ns), making them suitable for audio and video switching, automatic test equipment, precision data acquisition, battery-powered systems, sample-and-hold systems, and communication systems.
The ADG411, ADG412, and ADG413 are monolithic CMOS quad SPST switches designed on an enhanced LC‑MOS process. They provide low on‑resistance (< 35 Ω), ultralow power dissipation (35 pW), and a wide analog signal range that extends to the supply rails, making them suitable for audio, video, and precision data‑acquisition applications.
These devices operate from dual or single supplies (up to 44 V total) and feature TTL/CMOS‑compatible logic inputs, break‑before‑make switching, and low charge injection. Typical applications include audio/video switching, automatic test equipment, battery‑powered instruments, and sample‑and‑hold circuits.
| Supply voltage range (dual) | Vop = +16.5 V, Vss = –16.5 V |
|---|---|
| Maximum supply rating | 44 V |
| On‑resistance (Ron) | < 35 Ω |
| Power dissipation | 35 pW |
| Switching time (ton) | < 175 ns |
| Switching time (toff) | < 145 ns |
The on‑resistance is less than 35 Ω.
The devices are rated for a maximum supply voltage of 44 V.
Yes, they are TTL/CMOS‑compatible.
Typical switching times are ton < 175 ns and toff < 145 ns.
