The ADF4360-6 is a fully integrated integer-N synthesizer and voltage-controlled oscillator (VCO) designed for a center frequency of 1150 MHz. It features a wide output frequency range, programmable output power level, and a 3-wire serial interface.
The ADF4360-6 is a fully integrated integer‑N synthesizer and voltage‑controlled oscillator (VCO) designed for a center frequency of 1150 MHz, with an optional divide‑by‑2 output that yields 525 MHz to 625 MHz. It operates from a 3.0 V to 3.6 V supply and is controlled via a simple 3‑wire serial interface.
The document provides complete specifications, timing diagrams, absolute maximum ratings, pin descriptions, typical performance curves, package dimensions, and ordering information, enabling designers to integrate the device into wireless handsets, test equipment, LANs, and CATV applications.
| Output frequency range | 1050 MHz to 1250 MHz |
|---|---|
| Power supply voltage | 3.0 V to 3.6 V |
| Input high voltage | 15 V |
| Output power level | -13.5 dBm to -4.5 dBm (typ) |
| Phase‑noise (100 kHz offset) | -110 dBc/Hz (typ) |
| Operating temperature range | -40 °C to +85 °C |
The device covers an output frequency range from 1050 MHz to 1250 MHz.
It operates from a 3.0 V to 3.6 V supply.
The input high voltage (Vin) is specified as 15 V.
The typical phase‑noise is –110 dBc/Hz at a 100 kHz offset.
