The ADF4360-9 is an integrated integer-N synthesizer and voltage-controlled oscillator (VCO). External inductors set the ADF4360-9 center frequency. This allows a VCO frequency range of between 65 MHz and 400 MHz.
The ADF4360-9 is an integrated integer‑N synthesizer and voltage‑controlled oscillator (VCO) that provides a primary output frequency range of 65 MHz to 400 MHz. It operates from a 3.0 V to 3.6 V supply, supports 1.8 V logic, and offers a 3‑wire serial interface with digital lock‑detect and power‑down modes.
The document includes sections on functional block diagrams, absolute maximum ratings, timing characteristics, pin configuration, typical performance, output‑matching circuits, outline dimensions, and an ordering guide. It also provides detailed electrical specifications, recommended PCB design guidelines, and application examples such as system clock generation and wireless LANs.
| Primary output frequency range | 65 MHz to 400 MHz |
|---|---|
| Power supply voltage | 3.0 V to 3.6 V |
| Operating temperature range | -40 °C to +85 °C |
| Phase detector maximum frequency | 8 MHz |
The device can generate frequencies from 65 MHz up to 400 MHz.
It operates from a 3.0 V to 3.6 V power supply.
The specified operating temperature range is –40 °C to +85 °C.
The phase detector can handle up to 8 MHz.
