The OP470 is a high-performance monolithic quad operational amplifier with exceptionally low voltage noise, 5nV/√Hz@1kHz maximum, offering comparable performance to ADI's industry standard OP27. The OP470 features an input offset voltage below 0.4mV, excellent for a quad op amp, and an offset drift under 2mV/°C, guaranteed over the full military temperature range. Open loop gain of the OP470 is over 1,000,000 into a 10 kW load ensuring excellent gain accuracy and linearity, even in high gain applications. Input bias current is under 25nA, which reduces errors due to signal source resistance. The OP470's CMR of over 110dB guarantees excellent common mode rejection ratio over the full military temperature range.
The OP470 is a high‑performance monolithic quad operational amplifier offering very low voltage noise (5 nV/√Hz at 1 kHz) and excellent input offset voltage (≤0.4 mV). It provides high gain, low offset drift, and a unity‑gain stable design suitable for precision instrumentation and low‑noise active filters.
The document lists electrical characteristics, absolute maximum ratings, package dimensions, and ordering information for the 14‑lead DIP, 14‑lead plastic DIP, and 16‑lead SOIC versions. Detailed graphs illustrate noise density, gain‑bandwidth, slew rate, and other performance parameters across temperature and supply voltage ranges.
| Gain‑bandwidth product (typical) | 6 MHz |
|---|---|
| Input voltage range | +11 V to +12 V |
The OP470 has a typical gain‑bandwidth product of 6 MHz.
