The AD712 is a dual precision, low-cost, high-speed BiFET operational amplifier. It features enhanced AC performance, settling to ±0.01% in 1.0 μs, minimum slew rate of 16 V/μs (AD712J), and minimum unity-gain bandwidth of 3 MHz (AD712J). In terms of DC performance, it has a minimum open-loop gain of 200 V/mV (AD712K). The AD712 is available in single and quad versions, and can be used in a variety of applications.
The AD712 operational amplifier from Analog Devices offers high performance at modest cost. It features a low input offset voltage, fast settling (1 µs to 0.01 %), and a slew rate of 16 V/µs, making it suitable for DAC/ADC buffers and high‑speed integrators. The device is available in PDIP, SOIC_N and CERDIP packages and in several temperature‑grade versions (commercial, industrial, military).
Typical applications include active filters, photodiode pre‑amps, and high‑speed unity‑gain buffers. Detailed specifications, absolute maximum ratings, and typical performance curves are provided, along with an ordering guide for the various package options.
It is offered in 8‑lead PDIP, 8‑lead SOIC_N, and 8‑lead CERDIP packages.
