This document introduces the features and characteristics of Eaton GVX9000 drives.
This manual is intended for engineers, technicians and end‑users who install, commission, operate, and maintain the Eaton GVX9000 AF servo drive. It includes safety warnings, definitions, and the required procedures to ensure reliable and safe operation.
The document is organized into chapters covering an overview of the drive, storage and installation, step‑by‑step start‑up, detailed parameter settings, maintenance, troubleshooting, technical data, accessories, dimensions, and regulatory declarations.
| Voltage Class | 230 V |
|---|---|
| Model Number | GVX‑XXXA1‑2 |
| Maximum Applicable Motor Output (kW) | 0.75 – 37 kW |
| Maximum Output Voltage | 3‑Phase proportional to input voltage |
| Output Frequency Range | 0.1 – 400 Hz |
| Carrier Frequency | 1 – 15 kHz |
| Cooling Method | Natural fan cooled |
Chapter 4 lists a step‑by‑step Power‑Up Test procedure (section 4‑10) that should be followed after wiring preparation.
Appendix A – Technical Data contains tables with all electrical and mechanical specifications for the 230 V and 460 V versions.
