This manual covers safety warnings, proper grounding, and high‑voltage precautions required before installing or servicing the MVX9000 AC drive. It also details wiring, mounting, and environmental requirements to ensure reliable operation.
The document includes a complete description of parameter groups, start‑up procedures, troubleshooting codes, and technical data such as voltage class, motor output limits, and cooling system specifications. Appendices list accessories, dimensions, and the EU declaration of conformity.
| Voltage Class (230 V version) | 230 V |
|---|---|
| Voltage Class (460 V version) | 460 V |
| Rated Output Current (A) – 230 V | 2.5 A |
| Rated Frequency | 0.1 to 400 Hz |
| Cooling System | Forced air‑cooling |
| Ambient Temperature Range | -10 °C to 50 °C |
All power must be disconnected, and you must wait at least five minutes for the DC‑link capacitors to discharge before opening the drive.
No – the manual requires mounting on a perpendicular, non‑vibrating wall to prevent the unit from falling.
The drive is cooled by forced air‑cooling.
