This is a Silicon RF Power Semiconductors application note, which introduces the performance data of RD07MUS2B TETRA single-stage amplifier at f=350-400MHz, Vdd=7.2V.
This application note from Silicon RF Power Semiconductors provides measured RF performance of the RD07MUS2B TETRA single‑stage amplifier. It includes summary data, output‑power and input‑power characteristics, impedance versus frequency, and an equivalent circuit.
The document details test conditions (350‑400 MHz, Vdd = 7.2 V, Idq = 250 mA) and presents results such as output power levels of 3 W and 4 W, gain, efficiency, and input/output impedance for each frequency point.
