This document introduces the names and functions of various parts of the window air conditioner, as well as the operating sequence and the usage of the microcomputer controller. It also emphasizes the importance of obtaining the product release warranty certificate.
This manual explains how to operate the Sampo AW‑2205BR series air‑conditioner. It covers the power on/off key, temperature‑setting key, function‑switch key (cooling, de‑humidify, fan, auto), timer settings, wind‑direction adjustment, and the wireless remote control functions. Detailed button descriptions and indicator meanings are provided for both the wall‑mounted controller and the optional wireless remote.
Safety and installation information is also included. The guide specifies the required power‑line size, grounding, indoor and outdoor protection ratings, and the correct voltage ranges for 110 V and 220 V models. Instructions for filter cleaning, troubleshooting common faults, and emergency shutdown procedures are given to ensure reliable and safe operation. This manual is written in Japanese.
| Indoor protection rating | IPx0 |
|---|---|
| Outdoor protection rating | LPx4 |
| Input voltage (110 V model) | 198 V – 242 V |
Use the 温度設定 key to select the target temperature, typically between 26 °C and 30 °C.
