This document describes the installation and usage methods of a series of window air conditioners, including precautions before installation, installation steps, and fixing methods. It also mentions the operating environment and usage requirements of the air conditioner, as well as the moisture and dust protection level and safety regulations of the product.
This manual provides safety guidelines, installation procedures, and wiring requirements for the Sampo AW series split‑type air conditioners. It includes detailed instructions for mounting the indoor and outdoor units, connecting power and ground wires, and ensuring proper clearances.
Operating instructions cover the remote controller functions, temperature setting, mode selection, timer, sleep mode, and maintenance tips such as filter cleaning and drainage. Troubleshooting sections describe common fault symptoms and how to reset protection devices. This manual is written in Chinese.
| Indoor IP rating | IPx0 |
|---|---|
| Outdoor IP rating | IPx4 |
| Operating temperature (hot side) | 21 °C – 43 °C |
| Operating temperature (cold side) | 21 °C – 32 °C |
| Ground wire size | ≥2.5 mm² |
| Input voltage (110 V model) | 198 V – 242 V |
The outdoor exhaust opening must have at least 40 cm of free space to ensure proper cooling.
Unplug the power cord from the socket to prevent damage.
