The manual begins with safety guidelines, precautions before use, and detailed instructions for pipe and outdoor‑unit installation, including grounding and wiring requirements. It also lists component names and functions for both the indoor unit and the LCD remote controller.
Subsequent sections cover normal operation, energy‑saving modes, remote‑control usage, trial run procedures, and a full specification table for the indoor and outdoor units, helping users set up and maintain the system correctly. This manual is written in Chinese.
| Indoor Unit Dimensions | 750 x 250 x 200 mm |
|---|---|
| Outdoor Unit Dimensions | 680 x 530 x 220 mm |
The indoor unit should be installed at a height of at least 2.5 m to prevent children from touching it.
Use a dedicated 2.0 mm² single‑core copper cable; multi‑core or extension cords must not be used.
The remote controller works effectively up to 7 m from the indoor unit.
The indoor unit can operate between 21 °C (minimum) and 43 °C (maximum).
