This manual covers all essential information for the Sampo AM-PY series split‑type air conditioners. It includes safety regulations, pre‑use precautions, detailed descriptions of the indoor unit’s LCD controller, and step‑by‑step installation procedures for both indoor and outdoor units.
Additional sections explain how to set timers, adjust wind direction, use special functions such as sleep mode and power‑saving, perform routine maintenance, and troubleshoot common faults. Technical specifications for each model are listed at the end of the document. This manual is written in Japanese.
| Indoor unit dimensions (W×H×D) | 810 × 295 × 210 mm |
|---|---|
| Outdoor unit dimensions (W×H×D) | 800 × 555 × 300 mm |
| Recommended indoor‑unit installation height | 2.5 m |
| Indoor‑unit IP rating | IPX0 |
| Outdoor‑unit IP rating | IPX4 |
Press the timer key to program a scheduled power‑on or power‑off time; the timer can also be cancelled with the same key.
The indoor unit should be installed at a height of about 2.5 meters.
Use a copper insulated cable with a cross‑section of 3.5 mm² for the power line and at least 2.0 mm² for the grounding line.
The indoor side has an IPX0 rating, while the outdoor side is rated IPX4.
