This instruction manual is for the use of air-cooled box-type air conditioner, and introduces the characteristics and usage methods of the product, such as usage precautions, electronic control panel instructions, electronic control panel operation methods, and adjustment of the wind direction.
This manual explains the functions and controls of the indoor and outdoor units, including the electronic control board, wind direction settings, temperature and timer adjustments, and cleaning procedures. It also provides safety notes and troubleshooting tips for normal operation.
The guide covers how to set temperature (16‑30 °C), program timer (1‑12 h), enable quick‑cool, strong‑cool, auto‑wind, and air‑purification modes, as well as how to clean the filters and reset after a power interruption. This manual is written in Japanese.
| Temperature setting range | 16‑30 °C |
|---|---|
| Timer setting range | 1‑12 hours |
| Models covered | APF‑S051AM, APF‑S041AM |
Press the temperature up or down keys on the control panel to select a temperature between 16 °C and 30 °C.
Use the timer key to set a timer from 1 to 12 hours; each press increases the timer by one hour.
Open the front panel, remove the filter, and wash it according to the cleaning instructions shown in the manual.
