Sampo AW-SA18/SA20 Air Conditioner User Manual

This document is a technical bulletin for AW-SA18 and AW-SA20.

Brand: Sampo
Category: Air conditioner
Document type: User Manual
Language: Japanese
Pages: 16
File format: PDF
File size: 11.3 MB
Published: 19 March, 2012
Updated: 30 September, 2023
MD5 checksum: 3331D41EB9E0331DD52C16411C7E5727
PDF: Sampo AW-SA18/SA20 Air Conditioner User Manual PDF

About this manual

This manual covers the safe handling, installation, and operation of the Sampo AW‑SA18 and AW‑SA20 split‑type air‑conditioners. It includes safety regulations, required clearances, wiring instructions, and detailed component descriptions.

Key sections describe the installation procedure, control panel functions, operating modes, and troubleshooting steps such as checking power supply voltage and addressing abnormal condensation or noise. This manual is written in Japanese.

What's inside

Safety Guidelines
Installation Precautions
Component List
Installation Procedure
Operation Instructions
Troubleshooting
Specifications

Specifications

AW‑SA18 Dimensions	450 mm × 345 mm × 575 mm
AW‑SA20 Dimensions	460 mm × 355 mm

Frequently asked questions

What safety precautions are required before installing the unit?

Use a dedicated power line, ensure the grounding wire is at least 2.5 mm², keep indoor clearance of at least 50 cm and outdoor clearance of at least 100 cm, and follow the wiring specifications for the model.

What clearances are required for indoor and outdoor installation?

The indoor unit must have at least 50 cm of free space around it, and the outdoor unit must be installed with a minimum of 100 cm clearance from walls or other obstacles.
