The document introduces the features and characteristics of the MASTERLine ES 35W GU5.3 12V 36D 1CT product, including the use of EcoBoost technology for dual-color coated low-voltage halogen reflectors, high energy efficiency, and dimmable capability.
The Philips MASTERLine ES 35W is a GU5.3 base LED lamp designed for 12 V lighting systems. It provides a 36° beam angle and a colour temperature of 3000 K, making it suitable for residential and commercial use.
The datasheet lists key specifications such as 35 W rated power, 2.92 A current, 2200 cd maximum luminous intensity, CRI 100 Ra8, and a rated life of 5000 hours. Packaging details include a 4 × 5 F configuration and barcodes for product identification. This manual is written in Chinese.
| Rated Power | 35 W |
|---|---|
| Current | 2.92 A |
| Maximum Luminous Intensity | 2200 cd |
| Colour Rendering Index (CRI) | 100 Ra8 |
| Colour Temperature | 3000 K |
| Beam Angle | 36° |
| Rated Life | 5000 hr |
| Base Type | GU5.3 |
| Maximum Lamp Temperature | 380 °C |
The lamp has a rated power of 35 W.
The beam angle is 36 degrees.
The colour temperature is 3000 K.
