Lenovo Wanquan T220/T270 Server User Manual, which details the server's usage methods, precautions and safety regulations, etc.
This manual is intended for experienced technicians and administrators who install, configure, and maintain the Lenovo ThinkServer T220/T270. It begins with safety warnings, ESD precautions, and power‑off procedures to prevent injury and equipment damage.
Subsequent chapters describe the server’s hardware architecture, technical specifications, BIOS and RAID configuration, operating‑system installation guides for Windows, Linux, and Unix, and detailed troubleshooting procedures. Appendices include POST error codes, terminology, and network‑card information. This manual is written in Chinese.
| Processor support | 2 Intel Xeon (Nocona) processors, 2.8‑3.2 GHz |
|---|---|
| Memory type and capacity | ECC Registered DDR333 SDRAM, up to 8 GB |
| Disk subsystem I/O | Ultra320 SCSI1 and SAIA controllers, up to 320 MB/s |
| Network interface | Dual gigabit Ethernet, 1000 Mbps per port |
| Power input | 220 V AC, three‑pin grounded plug required |
The server uses a 220 V AC power supply and must be connected with a three‑pin grounded plug.
The server has six DIMM slots and supports up to 8 GB of ECC Registered DDR333 SDRAM.
It includes dual gigabit Ethernet ports, each capable of 1000 Mbps throughput.
Yes, the server supports Wake‑On‑LAN using the ACPI and Magic Packet standards.
