This manual covers everything needed to install and configure the ASRock E350M1/USB3 Mini‑ITX motherboard, including packaging contents, hardware specifications, and BIOS settings. It also explains how to connect front‑panel, audio, video, network, storage and USB interfaces.
Safety warnings, regulatory information and troubleshooting tips are included to help users avoid damage and ensure reliable operation. This manual is written in Chinese.
| CPU Support | AMD dual‑core Zacate E350/E350D APU |
|---|---|
| Chipset | AMD A50M |
| Memory Slots | 2 x DDR3 DIMM slots |
| Maximum Memory | 16 GB DDR3 non‑ECC, unbuffered |
| PCI Express Slot | 1 x PCI Express 2.0 x16 |
| Integrated Graphics | AMD Radeon HD 6310 |
| Video Outputs | D‑Sub, DVI‑D, HDMI |
| LAN | Realtek RTL8111E Gigabit Ethernet |
| SATA Ports | 4 x SATA3 6.0 Gb/s |
| USB 3.0 Ports | 2 x USB 3.0 (Etron EJ168A) |
| BIOS | 32 Mb AMI BIOS, UEFI Legacy BIOS |
It supports AMD dual‑core Zacate E350 and E350D APUs.
The board works with Windows 7/64‑bit, Windows Vista/64‑bit, Windows XP, Windows XP 64‑bit and Windows 7 Media Center.
Short the CLRCMOS1 jumper pins for about 5 seconds, then wait roughly 15 seconds before powering on again.
The motherboard can handle up to 16 GB of DDR3 non‑ECC, unbuffered memory.
