ASRock 880GM-LE FX Motherboard Installation Guide

Brand: ASRock
Category: Motherboard
Document type: Installation Guide
Language: English
Pages: 177
File format: PDF
File size: 7 MB
Published: 15 March, 2012
Updated: 30 September, 2023
Model: 880GM-LE
MD5 checksum: E5C620E161B4B3A8C3702C17CB3B9F3C
PDF: ASRock 880GM-LE FX Motherboard Installation Guide PDF

About this manual

This guide walks you through installing the ASRock 880GM-LE FX Micro ATX motherboard, describing the package contents, layout, and connector locations. It also explains BIOS features, overclocking tools, and the included support CD utilities.

Key sections cover CPU socket and memory installation, SATA and USB connections, integrated graphics and audio specifications, LAN configuration, and safety warnings for overclocking. The manual ends with troubleshooting tips and regulatory compliance information.

What's inside

Introduction
Package Contents
Specifications
Motherboard Layout
Rear Panel I/O
LAN
BIOS Feature
Unique Features
Overclocking Warning

Specifications

Form Factor	Micro ATX (9.6 in x 7.8 in)
CPU Socket	AM3+ (compatible with AM3)
Chipset	AMD 880G Northbridge / AMD SB710 Southbridge
Supported CPUs	AMD AM3+ and AM3 Phenom II, Athlon, Sempron
Integrated Graphics	AMD Radeon HD 4250
LAN Controller	Realtek RTL8111DL Gigabit
Audio Codec	Realtek ALC662 5.1 CH HD Audio
BIOS	8 Mb AMI BIOS
SATA Ports	6 SATA2 3.0 Gb/s connectors

Frequently asked questions

What CPU socket does the ASRock 880GM-LE FX motherboard use?

It uses an AM3+ socket and is also compatible with AM3 processors.

What integrated graphics chipset is included?

The motherboard includes the AMD Radeon HD 4250 integrated graphics.

Which LAN controller is provided on this motherboard?

It features a Realtek RTL8111DL Gigabit Ethernet controller.

Download PDF (7 MB)
