KFR-50LW/36ZBp air conditioner is composed of indoor unit, outdoor unit and related accessories. The indoor unit includes fan, evaporator, display panel, etc., and the outdoor unit includes compressor, fan, condenser, etc. The air conditioner can be controlled by the remote control to turn on and off, set the running mode, temperature, fan speed, air flow direction, etc.
The guide is intended for qualified installation technicians and explains the safety precautions that must be observed before and during installation, such as verifying power voltage, ensuring proper grounding, and avoiding corrosive environments. It also details the required tools and the recommended installation location for both indoor and outdoor units.
The manual describes the air‑conditioner’s main parts—including the indoor unit, outdoor unit, remote control, and display panel—along with their functions and operating buttons. Technical specifications such as cooling/heating capacities, power consumption, noise levels, and energy efficiency ratings are listed, and a testing procedure for compliance with GB/T 7725‑2004 is included. This manual is written in Chinese.
| Model | KFR-50LW/36ZBp |
|---|---|
| Rated power supply voltage | 220 V |
| Input voltage range | 178 V – 250 V |
| Rated frequency | 50 Hz |
| Cooling capacity (min/mid/max) | 1.8 kW / 2.5 kW / 6.0 kW |
| Heating capacity (min/mid/max) | 1.5 kW / 3.5 kW / 9.8 kW |
| Cooling input power (min/mid/max) | 0.48 kW / 0.68 kW / 2.40 kW |
| Heating input power (min/mid/max) | 0.44 kW / 0.95 kW / 3.27 kW |
| SEER (Cooling seasonal energy efficiency ratio) | 4.17 W/W |
| HSPF (Heating seasonal energy efficiency ratio) | 2.88 W/W |
| APF (Annual performance factor) | 3.13 W/W |
| Indoor fan airflow | 950 m³/h |
| Indoor noise level | 40 dB |
| Outdoor noise level | 49 dB |
| Weight (indoor/outdoor) | 40.0 kg / 52.0 kg |
Installation should be performed by qualified installation technicians who follow the instructions in this manual.
