The ASRock H61M/U3S3 motherboard, manufactured by ASRock, is reliable and offers excellent performance. It supports 2nd generation Intel® CoreTM i7/i5/i3 processors, features a solid capacitor design, supports DDR3 memory technology, and has multiple expansion slots and onboard graphics with various output options.
This manual introduces the ASRock H61M/U3S3 motherboard, covering its key features, supported CPUs, memory types, and expansion options. It also guides users through installation, BIOS configuration, and troubleshooting.
Additional sections detail the onboard connectors, SATA and USB ports, audio and video outputs, as well as environmental compliance and warranty information. This manual is written in Chinese.
| CPU socket | LGA1155 |
|---|---|
| Chipset | Intel H61 |
| Memory type | DDR3 (dual‑channel) |
| Maximum memory capacity | 16 GB |
| Onboard graphics | Intel HD Graphics 2000/3000 |
| Video outputs | D‑Sub, DVI‑D, HDMI |
| Audio codec | Realtek ALC662 5.1‑channel |
| LAN controller | Atheros AR8151 Gigabit Ethernet |
| USB ports | 4 × USB 2.0, 2 × USB 3.0 |
It uses an LGA1155 socket for second‑generation Intel Core i7/i5/i3 processors.
The motherboard includes two USB 3.0 ports.
The board supports up to 16 GB of DDR3 memory.
It supports Microsoft Windows 7/7 64‑bit, Vista/ Vista 64‑bit, and Windows XP/XP 64‑bit.
