ASRock P67 Transformer motherboard adopts ATX specification, supports Intel Core i7/i5 processors, and has a built-in 7.1-channel high-fidelity audio with content protection.
This manual introduces the ASRock P67 Transformer ATX motherboard, its key features, and where to find the latest drivers and BIOS updates on the ASRock website. It includes a quick‑start guide, detailed hardware specifications, and safety precautions for handling the board.
The document walks you through CPU, memory, and peripheral installation, BIOS configuration, driver installation, and troubleshooting using the on‑board debug LEDs. Environmental compliance and warranty information are also provided. This manual is written in Chinese.
| CPU socket | LGA1156 |
|---|---|
| Chipset | Intel P67 |
| Memory slots | 4 DDR3 DIMM slots |
| Maximum memory | 16 GB |
| SATA3 ports | 2 × 6.0 Gb/s |
| USB 3.0 ports | 2 rear ports |
| LAN controller | Realtek RTL8111E Gigabit |
| Audio codec | Realtek ALC892 |
It supports Intel Lynnfield Core i7 and i5 processors using the LGA1156 socket.
Supported OSes include Windows 7/7 64‑bit, Vista/ Vista 64‑bit, and Windows XP/XP 64‑bit.
