ASRock H61DE/S3 Motherboard is a ATX-sized motherboard that supports second generation Intel Core i7/i5/i3 processors, equipped with 4 DDR3 DIMM slots, supports DDR3 1333/1066 non-ECC, un-buffered memory, supports up to 16GB system capacity.
This guide introduces the ASRock H61DE/S3 motherboard, its packaging contents, and key features. It provides detailed specifications such as supported CPUs, memory, expansion slots, onboard graphics, audio, LAN, and storage interfaces.
The manual also explains jumper settings, connector layouts, BIOS access methods, and includes safety warnings, environmental information, and support resources. It is intended for users assembling or configuring a PC with this board. This manual is written in Chinese.
| USB Ports | 6 × USB 2.0 rear ports |
|---|
