ASRock H61DE/SI Motherboard is an ATX form factor motherboard that supports second generation Intel Core i7/i5/i3 processors, DDR3 1333/1066 memory, and up to 16GB system capacity.
This manual introduces the ASRock H61DE/SI ATX motherboard, covering its hardware features, supported CPUs, memory types, and integrated graphics. It also explains how to install the board, connect peripherals, and update the BIOS using the included tools.
Additional sections describe the rear panel connectors, onboard interfaces such as SATA, USB, and audio ports, as well as jumper settings for CMOS clearing and BIOS configuration. The document includes safety warnings, environmental compliance information, and links to online support resources. This manual is written in Chinese.
| Form factor | ATX (12.0" x 8.6") |
|---|---|
| Chipset | Intel H61 |
| Memory slots | 4 x DDR3 DIMM, up to 16 GB, 1333/1066 MHz |
| SATA ports | 4 x SATA2 3.0 Gb/s |
| USB ports | 6 x USB 2.0 (front) + 2 x additional USB 2.0 headers |
| Audio | Realtek ALC887, 7.1‑channel high‑definition |
| Video outputs | D‑Sub, DVI‑D, HDMI (max 1920×1200 @ 60 Hz) |
Press during the Power‑On Self‑Test (POST) to access the BIOS setup program.
