The Panasonic KX-FC538CN/FC538CN2 is a 2.4GHz digital cordless phone with ordinary paper fax, supports 6 handsets and has side-by-side talk, dual digital hands-free speakerphone, see more clearly, each room has a handset, supports 6 handsets, ordinary paper fax and other functions
The KX-FC538CN/FC533CN series is a 2.4 GHz digital cordless telephone with an integrated ordinary‑paper fax. It supports up to six sub‑handsets, offers a full‑digital answering system, and includes features such as caller ID, a 150‑entry phone book, and dual‑line back‑lit LCD display. The device operates on FHSS technology and provides clear voice communication and fax transmission.
Technical details include a working frequency of 2.40‑2.48 GHz, a modem rate of 9.6 kbps, and a fax transmission speed of about 15 seconds per page. The main unit measures 110.5 mm × 332.5 mm × 205 mm, weighs 2.9 kg, and requires 220‑240 V AC power (50/60 Hz). Panasonic recommends using only original consumables and accessories. This manual is written in Chinese.
| Working frequency | 2.40‑2.48 GHz |
|---|---|
| Modem data rate | 9.6 kbps |
| Fax transmission speed | 15 seconds per page |
| Maximum sub‑handsets | 6 |
| Phone book capacity | 150 numbers |
| Message record capacity | 15 minutes |
| Power supply | 220‑240 V, 50/60 Hz |
| Main unit dimensions (H×W×D) | 110.5 mm × 332.5 mm × 205 mm |
| Main unit weight | 2.9 kg |
Up to six sub‑handsets can be connected.
The fax transmits at about 15 seconds per page.
The modem operates at 9.6 kbps.
The device works between 2.40 GHz and 2.48 GHz.
