The Panasonic KX-FLB813CN is a multifunction laser fax machine that features a platform color scanner, 2-bin sorter, up to 18ppm print speed, 600 x 600dpi print resolution, 18 cpm copy speed and 33.6 kbps fax modem speed.
The KX-FLB813CN is a 4‑in‑1 multifunction laser fax machine that combines high‑speed printing, copying, scanning, and faxing in a compact tabletop design. It offers 18 ppm printing, 18 cpm copying, and a 33.6 kbps fax modem, with a 15‑second warm‑up time and dual‑bin paper handling for efficient workflow.
The device supports USB 2.0 connectivity to Windows 98/Me/2000/XP computers and includes a 40‑page automatic document feeder, a 250‑sheet paper tray, and optional multi‑purpose trays for labels, envelopes, and thick media. High‑resolution scanning is available up to 9600 × 9600 dpi (interpolated) with TWAIN drivers for PDF, JPEG, and TIFF output. This manual is written in Chinese.
| Print speed | 18 ppm |
|---|---|
| Print resolution | 600 × 600 dpi |
| Copy speed | 18 cpm |
| Maximum scan resolution (interpolated) | 9600 × 9600 dpi |
| Fax modem speed | 33.6 kbps |
| Memory (standard) | 32 MB |
| Power supply | AC 220‑240 V, 50/60 Hz |
| Maximum power consumption | ≈ 900 W |
| Dimensions (W × D × H) | 440 mm × 445 mm × 318 mm |
| Weight | ≈ 15.7 kg |
| Paper tray capacity | 250 sheets |
| Automatic document feeder capacity | 40 pages |
| USB interface | USB 2.0 |
The machine prints at 18 pages per minute.
It can store up to 150 pages for transmission and up to 170 pages for reception.
