This document introduces the Philips HD4686/90, HD4686/60, HD4686/30, HD4685/90, HD4685/60, and HD4685/30 models. The document provides information such as general description, important information, and safety warnings.
This manual introduces the Philips electric kettle range, describing the lid, control panel, temperature lights and safety warnings. It explains how to register the product and provides a quick start guide for first use.
Detailed sections cover boiling water, setting temperature, keep‑warm function, cleaning, descaling and troubleshooting. Safety information includes warnings about over‑filling, electrical load and boil‑dry protection. This manual is written in Chinese.
| Maximum current draw | 13 A |
|---|---|
| Minimum water volume | 0.5 L |
| Temperature settings | 100 °C / 90 °C / 80 °C / 40 °C (or 70 °C for beige‑wood brown model) |
| Keep‑warm duration | 30 minutes |
| Boil‑dry protection | Automatic shut‑off when no water |
Press the SET TEMP button one or more times; the selected temperature light will flash and then stay on when the set temperature is reached.
Remove the filter from the kettle, slide the basket off, clean the stainless‑steel mesh under running water, brush the filter, then reassemble.
Never fill beyond the maximum level indication; over‑filling can cause water to be ejected from the spout and cause scalding.
If the kettle is switched on with no water, it automatically turns off; after 10 minutes you can lift the kettle to reset the protection.
