This document describes the features and characteristics of Vishay Draloric TNPU e3 High Precision Thin Film Flat Chip Resistors, including low temperature coefficient, tight tolerances, superior moisture resistivity, and waste gas resistance. The product is suitable for various applications such as industrial equipment, telecommunication, medical equipment, instrumentation, test and measuring equipment, and automotive.
The Vishay TNPU e3 series provides high‑precision thin‑film chip resistors with tight tolerance (+0.05 %) and low temperature coefficient (+5 ppm/K). They are designed for industrial, telecommunication, automotive, medical, and instrumentation applications, offering superior moisture resistivity and RoHS compliance.
The document lists electrical specifications, dimensions, packaging options, production processes, and extensive test procedures. It also includes environmental compliance information and a legal disclaimer. All data are based on Vishay’s standard test methods and IEC standards.
| Rated dissipation (TNPU1206 e3) | 0.25 W |
|---|---|
| Operating voltage (TNPU1206 e3) | 200 V |
| Moisture resistivity | < 0.25 % (85 °C, 56 days, 85 % RH) |
| Climatic category | 55/125/56 |
Yes, the resistors are RoHS compliant.
The TNPU1206 e3 can operate up to 200 V.
