The document introduces the features and applications of the SLF series inductors, including low DC impedance, high current handling capability, suitability for high-density assembly structures, etc.
The SLF7028 is part of the SLF series of low‑profile, high‑current inductors designed for high‑density automatic equipment. It is suitable for use in mobile phones, personal electronics, hard‑disk drives, and other electronic devices.
The document lists physical dimensions, operating temperature ranges, packaging formats, and electrical characteristics such as inductance values and maximum rated current. Recommended PCB layout and tolerance information are also included. This manual is written in Japanese.
| Dimensions (L×W×T) | 6.0 × 6.0 × 2.8 mm |
|---|---|
| Operating Temperature Range | -20 °C to +85 °C |
| Maximum Rated Current | 0.96 A |
| Packaging | Tape and reel, 1000 pieces per reel |
| Inductance (µH) | 0.037 |
The SLF7028 measures 6.0 mm × 6.0 mm × 2.8 mm (L × W × T).
It can operate from –20 °C up to +85 °C.
The maximum rated current is 0.96 A.
It is supplied in tape‑and‑reel format, 1000 pieces per reel.
