This document introduces the eNeciveD RFID 726 technical guide, manual overview, standard certification model list, and related information. It includes the features and characteristics of the wireless unit WD30, such as high anti-interference capability and long communication distance.
This manual describes the Omron WD30 series DeviceNet wireless units, including the ME and SE variants. It outlines the communication parameters such as frequency band, data rate, and power, as well as the maximum I/O points and channel counts supported by the devices.
Installation, wiring, and configuration procedures are covered, together with a list of accessories and recommended hardware modules. The document also includes environmental limits and mechanical dimensions for proper integration into automation systems. This manual is written in Chinese.
| Maximum input points | 1600 (100 channels) |
|---|---|
| Transmit power | 10 mW |
| Data rate | 100 kbit/s |
| Operating temperature | -10 °C to +50 °C |
| Storage temperature | 0 °C to 165 °C |
| Maximum channels | 57 |
| Maximum sub‑devices | 64 |
The device supports a data rate of 100 kbit/s.
