The G6J-Y series is a super-compact 2-pole slender type relay produced by Panasonic. The coil contact has high AC1,500V voltage resistance and 2.5 kV 2×10µs impact voltage resistance. The coil and the same-pole contacts are FCC part68 (1.5 kV 10×160µs) standard. It is equipped with a 1-coil locking type and considers energy saving. Standard models have UL/CSA specifications.
The G6J-Y series are ultra‑small 2‑pole surface‑mount relays with a high‑density package (5.7 mm × 10.6 mm × 9 mm). They are offered in single‑stable and latching versions, with short (FS) or long (FL) terminals. The relays meet UL/CSA safety certifications and FCC Part 68 high‑voltage standards.
The document provides detailed electrical characteristics (coil voltage 3 V‑24 V DC, contact voltage up to AC 1500 V, contact resistance ≤100 mΩ), mechanical data, recommended soldering conditions, and packaging options (rod or tape, the latter indicated by a “‑TR” suffix). It also includes usage notes for continuous power applications and handling precautions. This manual is written in Chinese.
| Package size | 5.7 mm × 10.6 mm × 9 mm |
|---|---|
| Contact rating | 2 poles (2C) |
| Soldering temperature | ≈250 °C (260 °C for DWS) |
Use a soldering temperature of about 250 °C (260 °C for DWS processes).
Add the suffix “‑TR” to the part number when ordering to request tape packaging.
