F3W-A/C is an infrared light sensor that works by detecting the passage of an object. It is a short-type area sensor that is ideal for detecting objects with irregular passage positions. The sensor uses 10mm spacing between light axes and supports 10 light axes, with a detection distance of 90mm and a maximum detection width of 230mm.
This manual provides detailed information for the Omron F3W‑A/C series area sensors, including rated performance, characteristic data, wiring diagrams, and proper usage guidelines. It also lists accessories, connection methods, and safety precautions for installing the sensor in industrial environments.
The document covers installation steps, recommended mounting configurations to avoid mutual interference, and warranty terms. Technical specifications such as detection distance, optical axis pitch, power requirements, and environmental limits are presented for each model variant. This manual is written in Japanese.
| Detection distance | up to 5 m |
|---|---|
| Optical axis pitch | 10 mm / 20 mm / 40 mm |
| Power supply voltage | DC 12‑24 V (≤10 % ripple) |
| Consumption current | ≤100 mA (≤150 mA for 16‑24 mm pitch) |
| Control output | Open‑collector, ≤30 V, ≤100 mA |
| Response time | ≤12 ms |
| IP protection rating | IP62 |
| Mass (packed) | ≈580 g |
It requires a DC supply of 12 V to 24 V with ripple less than 10 %.
The sensor complies with IEC IP62 protection.
The sensor can detect objects up to 5 meters away, depending on the model.
