SiCompact A2 MAXI is a 1000/2000W metal halide lighting fixture produced by Siteco. It has a remote control gear, a safety cover glass, an asymmetrical light distribution, a wide beam, and a pressure equalization system with air-permeable connector for avoidance of condensation. It can also realize a hot instant restrike type with a restriking period less than 1 mil.
The SiCompact A2 MAXI is a compact high‑grade lighting fixture designed for traffic and public area applications. It features a die‑cast aluminum housing, asymmetrical light distribution and a narrow beam.
The sheet provides key specifications such as a 220‑230 V, 50 Hz supply, 9.6‑11.3 A current draw, IP65 ingress protection, and lamp wattage options of 1 000 W or 2 000 W. The unit weighs 26 kg and includes safety features like a protective glass cover and tool‑free lamp replacement.
| Dimensions (Ay) | 0.13 m |
|---|---|
| Weight | 26.0 kg |
| Supply Voltage | 220‑230 V / 50 Hz |
| Current | 9.6‑11.3 A |
| Lamp Wattage | 1 000 W / 2 000 W |
| Color Temperature | 5 900 K / 5 800 K |
It operates on 220‑230 V at 50 Hz.
The fixture weighs 26.0 kg.
The unit can be equipped with 1 000 W or 2 000 W lamps.
