RING 4024PMH is a super high definition industrial barcode printer, with a print resolution of up to 600dpi, which is very suitable for printing electronic product labels, clothing tags, clothing washing labels, etc. The high-speed 32-bit RISC CPU processor and 16MB of memory make the printing data processing speed reach a very high level; the built-in label peeler and diversified printing modes can meet the different needs of different users.
The RING 4024PMH is a high‑resolution (600 dpi) barcode label printer designed for a variety of applications such as tags, clothing labels, and logistics. It features a 32‑bit RISC CPU, 16 MB DRAM and 4 MB Flash ROM, and supports multiple barcode formats including MaxiCode and PDF417.
The printer offers a maximum print width of 104 mm, a print speed up to 60 m/min, and an RS‑232 communication interface. It can handle media rolls up to 203 mm outer diameter with a 76 mm core, and supports media types such as polyester, polypropylene, and waterproof labels. This manual is written in Chinese.
| Resolution | 600 dpi (24 dots/mm) |
|---|---|
| Maximum Print Width | 104 mm |
| Print Speed | Max 60 m/min |
| Memory | 16 MB DRAM, 4 MB Flash ROM |
| Communication Interface | RS‑232 |
| Weight | 12.5 kg |
| Media Roll Diameter | Max 203 mm outer, 76 mm inner |
| Supported Barcodes | Various including MaxiCode, PDF417, DataMatrix |
It prints at 600 dpi (24 dots per mm).
The printer uses an RS‑232 interface.
The maximum printable width is 104 mm.
It has 16 MB of DRAM and 4 MB of Flash ROM.
